EKKO EA15D Semi-Electric Straddle Stacker - 3300lbs Capacity

In stock
SKU: EA15D
Regular price $4,150.00
Est. Ship Date: Wednesday, March 13th

  • 3300lbs Load Capacity
  • 138-Inch Lift Height
  • Adjustable Forks and Legs

Trusted By

EKKO EA15D Semi-Electric Straddle Stacker - 3300lbs Capacity

The EKKO EA15D Semi-Electric Straddle Stacker is a blend of the functionality of a forklift and the convenience of a pallet stacker. Perfect for various applications such as loading and unloading trucks, and operating in stock rooms, manufacturing floors, and warehouses, this stacker is a reliable and efficient material handling solution. With a load capacity of 3,300 lbs and a raised height of 138 inches (11.5ft), the EA15D is constructed from high-quality steel and components, ensuring durability and resilience across diverse terrains and applications.

Key Features:

  • High Load Capacity: Able to handle loads up to 3,300 lbs, suitable for a wide range of tasks.
  • Adjustable Forks and Legs: Ensures versatility for handling different pallet sizes and shapes.
  • Power Lifting with Manual Drive: Combines ease of lifting with the simplicity of manual maneuverability.
  • Built-in Charger and Battery: Includes a 12V 120Ah battery and 12V/15A charger for consistent and convenient power.
  • Ergonomic Design: Features an ergonomic handle for comfortable operation.
  • Robust Construction: Steel is built with robotic welding for enhanced strength and durability.
  • Warranty: Comes with a 3-year limited warranty for added peace of mind.

Specifications:

  • Model: EA15D
  • Lifting Height Max: 138 inches
  • Fork Length: 45.3 inches
  • Service Weight: 1,450 lbs

EKKO EA15D Semi-Electric Straddle Stacker: An ideal choice for businesses looking for a powerful, versatile, and durable material handling solution.

              Model



              EA15D

              Load Capacity

               (lb)

              3300

              Lifting height Max.

              (in)

              138

              Load center distance

              (in)

              24

              Fork length

              (in)

              45.3

              Single fork width

              (in)

              4

              Overall fork width

              (in)

              8-32.7

              Lowered fork height

              (in)

              2.35

              Fixed leg length

              (in)

              36.5

              Fixed leg width, single

              (in)

              3.94

              Adjustable legs

              (in)

              44.5-59.1

              Turning radius

              (in)

              52.6

              Overall length

              (in)

              70

              Overall width  max

              (in)

              61

              Extended mast height

              (in)

              154

              Lowered mast height

              (in)

              92

              Battery Voltage

              (V/Ah)

              12V/120Ah

              Charger

               (V/A)

              12V/15A

              Lift Motor

               (V/W)

              DC 12V/1500W

              Service Weight

               (lb)

              1450
