EKKO EK30SLP Liquid Propane 4 Wheel Forklift - 6000 lbs Capacity
The EKKO EK30SLP Liquid Propane 4-Wheel Forklift is an exceptionally crafted material handling solution designed for various industrial and warehousing applications. This forklift, with a load capacity of 6000 lbs and a lift height of 189 inches, is powered by a Tier 4 EPA compliant PSI engine, offering both efficiency and environmental responsibility. It combines advanced ergonomics and engineering to ensure optimal performance in warehousing and distribution tasks.
Key Features:
- High Load Capacity: Efficiently handles up to 6000 lbs, suitable for heavy-duty applications.
- Extended Lift Height: Achieves a maximum lift height of 189 inches, ideal for high stacking needs.
- Ergonomic Design: Features a semi-suspension seat, a small steering wheel, and electro-hydraulic direction changing for enhanced driving comfort.
- Low Emission Engine: Compliant with CARB 4 regulations, ensuring eco-friendly operations.
- Energy Efficiency: Optimized hydraulic system for reduced fuel consumption and increased energy efficiency.
- Robust Construction: Made from high-quality steel with durable components for long-lasting use.
- Smooth Operation: The cushion connection and suspension cab effectively absorb vibrations, while the lowering damping device reduces noise and shock.
Specifications:
- Model: EK30SLP
- Service Weight: 10,785 lbs
- Overall Length (with/without forks): 140 in / 97.8 in
- Engine: Mitsubishi 4G64 (PSI Engine), rated at 64 HP/2700 rpm
EKKO EK30SLP Liquid Propane Forklift: A powerful, environmentally friendly, and comfortable forklift solution, perfect for a range of material handling tasks in warehousing and distribution.
|
Model |
|
EK30SLP |
|
Drive type |
|
LPG |
|
Type of operation |
|
Propane |
|
Load Capacity |
LBS |
6000 |
|
Load Center |
in |
24 |
|
Lift height |
in |
189 |
|
Wheelbase |
in |
58 |
|
Service Weight |
LBS |
10785 |
|
Tire material |
|
Pattern Cushion Tire |
|
Wheel size(Front / Rear) |
in |
21x8-15/16x6-10.5 |
|
Service Brake |
|
Hydraulic Floor Pedal |
|
Overall width |
in |
44 |
|
Overall length with forks |
in |
140 |
|
Overall length without forks |
in |
97.8 |
|
Min ground clearance (at the mast) |
in |
3.5 |
|
Max traveling speed (loaded/unloaded) |
mph |
10.8/10.8 |
|
Mast Overall height |
in |
88 |
|
Free lifting height |
in |
39 |
|
Backrest height (from the surface of the forks) |
in |
48 |
|
Fork Size |
in |
42x4.9x1.77 |
|
Battery |
V/ Ah |
12/60 |
|
Engine Mode |
|
Mitsubishi 4G64 (PSI Engine) |
|
Engine rated power |
HP/rpm |
LPG: 64/2700 |
